Summit 24 Inch Outdoor Rated Kegerator with Solid Door

Maximize your outdoor entertaining experience with the Summit 24 Inch Outdoor Rated Kegerator. This impressive kegerator is equipped with durable and weatherproof construction, ensuring your favorite brews stay fresh and cold. With a spacious interior and adjustable temperature control, you can easily serve up perfectly chilled draft beer for all your guests to enjoy.

Features

• Large Capacity Kegerator
  5.6 cu.ft. interior can accept a full half barrel, quarter keg, or up to three sixth barrels or Cornelius style kegs.

• Weatherproof Design
  Solid 304 grade stainless steel construction allows safe placement outdoors.

• Built-in Capable
  Front-breathing design allows fully recessed installation under counters.

• Complete Tap Kit
  Includes 5 lb. CO₂ tank, regulator, draft arm, Sankey American tap, and connection hardware.

• Automatic Defrost
  Reduces user maintenance with auto defrost operation.

• Digital Thermostat
  Electronic controls ensure easy temperature management, with external readout in Celsius or Fahrenheit.

• Tap Cool System
  Interior tube extends cold air flow into the draft tower, keeping tapped beer cold.

• Stainless Steel Floor Cover
  Protects the interior floor when loading kegs.

• Top Guard Rail (Ships Unassembled)
  Attractive chrome guard rail helps reduce spills and neatens service.

• Stainless Steel Drip Tray
  Removable two-piece drip tray catches spills for easier cleanup.

• Adjustable Shelves
  Includes 2 chrome shelves with six placement options, allowing use as a beverage refrigerator.

• Memory IC Function
  Recovers last settings in case of power outage.

• Reversible Door
  User-reversible door swing for added flexibility.

• Casters Included (Ship Unassembled)
  Four casters (two locking) provide easy portability.

• Pro Style Handle
  Stainless steel handle adds a professional touch.

• Fully Finished Stainless Steel Cabinet
  Allows the dispenser to be used freestanding.

• Sealed Back
  Space-saving design with easier cleanability.

• 100% CFC Free
  Environmentally friendly design without ozone-damaging chemicals.

• CARB Compliant
  Eco-friendly hydrocarbon-based refrigerant for a greener footprint.

Specifications

• Capacity: 5.6 cu.ft. (159 L)

• Defrost Type: Automatic

• Door Material: Stainless Steel

• Cabinet Material: Stainless Steel

• US Electrical Safety: ETL

• Canadian Electrical Safety: ETL-C

• Sanitation Certification: ETL-S

• Energy Usage: 305.0 kWh/year

• Amps: 1.25

• Voltage/Frequency: 115 V AC / 60 Hz

• Weight: 120.0 lbs. (54 kg)

• Parts & Labor Warranty: 1 Year

• Compressor Warranty: 5 Years

• UPC: 761101083926

• Door Swing: RHD (Right Hand Door)

• Reversible Door: Yes

• Tap Kit Included: Yes

• Height with Tap: 51.5" (131 cm)

• Number of Taps: 1

• Adjustable Shelves: Yes

• Shelf Type: Chrome

• Shelf Quantity: 2

• Thermostat Type: Digital

• Fan Type: Interior and Exterior

• Refrigerant Type: R600a

• Refrigerant Amount: 1.06 oz.

• High Side Pressure: 150.0 PSI

• Low Side Pressure: 50.0 PSI

• Interior Height: 26.75" (68 cm)

• Interior Width: 20.0" (51 cm)

• Interior Depth: 19.0" (48 cm)

• Leveling Legs Quantity: 4

• Wheel Quantity (Casters): 4

• Temperature Range: 34°F to 68°F (1°C to 20°C)

• Sound Level: 34.0 dB

Dimensions

• Nominal Height: 34 Inches

• Height of Cabinet: 33 5/8 Inches

• Nominal Width: 24 Inches

• Width: 23 3/4 Inches

• Nominal Depth: 24 Inches

• Depth: 24 Inches

• Depth with Handle: 26 1/4 Inches

• Depth with Door at 90°: 46 3/4 Inches

Manuals

Summit Assembly Drawing

Summit Brochure

Summit Use and Care
