Summit 19 Inch Outdoor Beverage Center with Panel Ready Glass Door

Elevate your outdoor entertainment space with the Summit 19 Inch Outdoor Beverage Center. Featuring a panel-ready glass door, this stylish cooler keeps drinks chilled and ready to enjoy. Designed for outdoor use, it is durable and convenient, providing the perfect addition to any outdoor gathering.

Features

• Shallow depth
  Unique 17 3/4" depth is ideal for home wet bars, island kitchens, and other applications with limited footprint space
• Built-in capable
  Make the best use of space by installing your refrigerator under the counter
• Panel-ready door trim
  Door frame can be customized with a custom overlay panel (panel frame dimensions: 31 9/16" H x 18 3/4" W at 3/4" minimum thickness)
• Weatherproof design
  Approved for use in the outdoors, with a sealed exterior and double pane tempered glass door
• Commercially approved
  ETL-S listed to NSF-7 standard and meets UL-471 for use in commercial settings
• Stainless steel wrapped exterior
  Cabinet features 304 grade stainless steel construction for added durability and a professional look
• Double pane tempered glass door
  Heat resistant design provides clear view of stored products
• Automatic defrost
  Reduced user maintenance with auto defrost system
• Adjustable shelves
  Three glass shelves with six positions for optimal storage and easy cleaning
• LED lighting
  Automatically illuminates when the door is open for an attractive and energy efficient view
• White interior finish
  White interior offers improved visibility of stored contents
• Adjustable thermostat
  Dial thermostat with seven temperature settings offers easy temperature management
• Versatile construction
  Meets both residential and commercial standards
• Sealed back
  Space saving design with easier cleanability and added protection from the elements
• Right-angle plug
  Provides flexibility in unit placement without needing added depth
• Factory installed lock
  Door includes a lock and key for optional security. If planning to use the lock, be sure to include a 5/8" hole in the lower center of your custom panel
• Height adjustable
  Four leveling legs allow you to adjust the height between 33 7/8" and 34 1/2" to best fit your undercounter space
• Fully finished cabinet
  Allows the unit to be used freestanding
• 100% CFC free
  Environmentally friendly design does not contain ozone-damaging chemicals
• CARB Compliant
  Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Specifications

• Capacity: 3.13 cu.ft. (89 L)
• Defrost Type: Automatic
• Door: Glass / Panel-Ready Frame
• Cabinet Finish: Stainless Steel
• US Electrical Safety: ETL
• Canadian Electrical Safety: ETL-C
• Sanitation Certification: ETL-S (Commercial NSF-7)
• Energy Usage (Annual): 285.0 kWh/year
• Electrical Requirements: 115 V AC / 60 Hz
• Amperage: 1.3 Amps
• Weight: 85.0 lbs. (39 kg)
• Parts & Labor Warranty: 1 Year
• Compressor Warranty: 5 Years
• Door Swing: RHD
• Reversible: Factory Reversible
• Height Adjustable: Yes
• Shelf Type: Glass
• Shelf Qty: 3
• Adjustable Shelves: Yes
• Can Storage: Yes
• Thermostat Type: Dial
• Fan Type: Interior
• Refrigerant Type: R600a
• Refrigerant Amount: 0.88oz.
• High Side PSI: 320.0
• Low Side PSI: 120.0
• Level Legs Qty: 2
• Interior Light: Yes
• Temperature Range: 34 to 50ºF
• Sound Level: 32.6 dB

Dimensions

• Interior Height: 29 Inches
• Interior Width: 16 Inches
• Interior Depth: 12 3/4 Inches
• Compressor Step Height: 7 Inches
• Compressor Step Width: 16 Inches
• Compressor Step Depth: 6 1/4 Inches
